Diesel Generator Sets Powered By Perkins Engine 50hz/1500rpm

Diesel Generator Sets Powered By Perkins Engine 50hz/1500rpm


Availability:

Quantity:



Inquire Add to Basket

Silent Diesel Generator Sets Diesel Generator Sets Generators Cummins Generator Sets High-Power Generator Sets

Product Description

Genset Model	Genset output				Technical Data of Diesel Engine
	Prime		Standby		Engine model	Cylinder	Displacement	Fuel consumption	Alternator	Silent Type Size	Weight
	KW	KVA	KW	KVA	Engine model	L	L	L/h	Alternator	mm	KG
GFC-8P	7	8	7.7	9.6	403A-11G1	3L	1.131	3	KLG164B	1800×880×1050	670
GFC-8P	7	8	7.7	9.6	403D-11G	3L	1.131	2.6	KLG164B	1800×880×1050	670
GFC-12.5P	10	12.5	11	14	403D-15G	3L	1.496	3.6	KLG164C	1900×880×1080	680
GFC-12.5P	10	12.5	11	14	403A-15G1	3L	1.496	3.7	KLG164C	1900×880×1080	680
GFC-15P	12	15	13.2	16.5	403A-15G2	3L	1.496	5	KLG164D	1900×880×1080	695
GFC-20P	16	20	17.6	22	404A-22G1	4L	2.216	5.3	KLG184ES	1970×880×1130	796
GFC-20P	16	20	17.6	22	404D-22G	4L	2.216	5.3	KLG184ES	1970×880×1130	796
GFC-30P	24	30	26.4	33	1103A-33G	3L	3.3	7.2	KLG184G	2280×1000×1200	999
GFC-45P	36	45	40	50	1103A-33TG1	3L	3.3	10.8	KLG224C	2280×1000×1200	1064
GFC-60P	48	60	53	66	1103A-33TG2	3L	3.3	14.6	KLG224E	2400×1000×1300	1179
GFC-62.5P	50	62.5	55	69	1104A-44TG1	4L	4.4	14.8	KLG224E	2500×1000×1300	1257
GFC-80P	64	80	70	88	1104A-44TG2	4L	4.4	15.66	KLG224G	2550×1000×1300	1357
GFC-80P	64	80	70	88	1104C-44TAG1	4L	4.41	18.6	KLG224G	2850×1100×1600	1531
GFC-100P	80	100	88	110	1104C-44TAG2	4L	4.41	22.6	KLG274C	2850×1100×1600	1561
GFC-135P	108	135	119	149	1106A-70TAG1	6L	7.01	26.29	KLG274E	3200×1100×1600	1882
GFC-150P	120	150	132	165	1106A-70TAG2	6L	7.01	31.64	KLG274F	3300×1100×1600	1965
GFC-180P	144	180	158	198	1106A-70TAG3	6L	7.01	38.22	KLG274G	3350×1100×1600	2059
GFC-200P	160	200	176	220	1106A-70TAG4	6L	7.01	42.35	KLG274H	3400×1100×1600	2136
GFC-200P	160	200	176	220	1206A-E70TTAG1	6L	8.8	44.6	KLG274H	3450×1250×1850	3370
GFC-225P	180	225	198	248	1206A-E70TTAG2	6L	8.8	48.6	KLG274J	3500×1250×1850	3550
GFC-250P	200	250	220	275	1206A-E70TTAG3	6L	8.8	56	KLG274K	3500×1250×1850	3550
GFC-300P	240	300	264	330	1506A-E88TAG5	6L	8.8	65	KLG314D	3900×1450×2200	3763
GFC-350P	280	350	308	385	2206C-E13TAG2	6L	12.5	75	KLG314F	4200×1450×2200	4533
GFC-400P	320	400	360	450	2206C-E13TAG3	6L	12.5	85	KLG314F	4300×1450×2200	4663
GFC-450P	360	450	396	495	2506C-E15TAG1	6L	15	99	KLG354C	4500×1700×2250	5076
GFC-500P	400	500	440	550	2506C-E15TAG2	6L	15	106	KLG354D	4500×1700×2250	5236
GFC-600P	480	600	528	660	2806C-E18TAG1A	6L	18.1	129	KLG354E	4650×1900×2450	6000
GFC-650P	520	650	572	715	2806A-E18TAG2	6L	18.1	132	KLG354F	4650×1900×2450	6135
GFC-750P	600	750	660	825	4006-23TAG2A	6L	22.921	155	KLG404C	20GP	7550
GFC-800P	640	800	704	880	4006-23TAG3A	6L	22.921	172	KLG404D	20GP	7600
GFC-900P	720	900	800	1000	4008TAG1A	8L	30.561	215	KLG404E	20GP	8550
GFC-1000P	800	1000	880	1100	4008TAG2A	8L	30.561	215	KLG404F	20GP	8600
GFC-1250P	1000	1250	1100	1375	4012-46TWG2A	12V	45.842	259	KLG404H	40HC	11600
GFC-1350P	1080	1350	1188	1485	4012-46TWG3A	12V	45.842	283	KLG454B	40HC	11700
GFC-1500P	1200	1500	1320	1650	4012-46TWG4A	12V	45.842	316	KLG454C	40HC	11850
GFC-1500P	1200	1500	1320	1650	4012-46TAG2A	12V	45.842	310	KLG454C	40HC	12100
GFC-1688P	1350	1688	1485	1856	4012-46TAG3A	12V	45.842	370	KLG454D	40HC	14000
GFC-1850P	1480	1850	1628	2035	4016TAG1A	16V	61.123	389	KLG454E	40HC	14500
GFC-2000P	1600	2000	1760	2200	4016TAG2A	16V	61.123	400	KLG454F	40HC	14700
GFC-2000P	1600	2000	1760	2200	4016-61TRG2	16V	61.123	422	KLG454F	40HC	15100
GFC-2250P	1800	2250	1980	2475	4016-61TRG3	16V	61.123	470	KLG454H	40HC	15300
